Pooks Parts 1987-Present 39mm Fork Lower

1987-Present 39mm Fork Lowers

Update your 39mm fork lower from something worn out with a much cleaner and much more updated look with Pooks Parts 39mm Fork Lower. Made from high quality steel with a clean chrome finish and updated oil sealing, which is the same for all Pooks Parts Fork Lowers. Installation is quick and easy.

Custom Made - Made To Order

This product is made to order. Allow 4 to 6 weeks lead-time. Contact us for any custom applications or request.

If you're not sure about sizing or need something custom feel free to reach out.

Measurements

Measure from bottom of lower to the bottom of the triple tree for most accurate length. 3 to 4 inches of travel clearance is recommended.

Features

• 39mm fork lowers.
• Stock to 12+ over. (Hamburger mechanical mount available)
• Stock overall lower length 16.25 inches.
• Made from high quality steel.
• Chrome and raw steel finish.
• Oil seals and bushings pre installed.
• New crush washers.
• Axle and spacers sold separately.

Installation instructions

1. Remove old fork tube.
2. Inspect fork tube for any damage.
3. Lightly coat inside of fork lower and seal with fork oil.
4. Remove bottom bushing on inner fork tube. Bushings are pre installed so it will not be needed.
5. Carefully slide fork lower over inner fork tube making sure you do not damage the oil seal.
6. Tighten dampener bolt and crush washer to Harley Davidson torque spec.
7. Fill fork tube with 10.5 – 11.2 oz. of fork oil based on application. (We recommend type E or 15w.)
8. Enjoy.

Note: Fork lowers DO NOT extend the length of your front end. New extended inner fork tubes are required based on application. Stock axle will not work without modification. Custom axles and spacers sold below.
